Binder 9010-0082 - Page 45

BD / ED / FD (E2) 03/2019 page 45/68
Chamber size FD 23 FD 53 FD 115 FD 240
Interior dimensions
Width
mm / inch 222 / 8.74 400 / 15.75 600 / 23.62 800 / 31.50
Height
mm / inch 330 / 12.99 400 / 15.75 480 / 18.90 600 / 23.62
Depth
mm / inch 277 / 10.91 330 / 12.99 400 / 15.75 500 / 19.69
Interior volume
l / cu.ft. 20 / 0.7 53 / 1.9 115 / 4.1 240 / 8.6
Steam space volume
l / cu.ft. 36 / 1.27 77 / 2.72 158 / 5.58
308 / 10.88
Racks
Quantity of racks (regular) 2 2 2 2
Quantity of racks (max.) 4 5 6 7
Load per rack
Kg / lbs 12 / 26 15 / 33 20 / 44 30 / 66
Permitted total load
Kg / lbs 25 / 55 40 / 88 50 / 110 70 / 155
Weight
Weight (empty)
Kg / lbs 28 / 62
44 / 97
62 / 137 96 / 212
Temperature data
Temperature range, 5 °C above ambient
up to
°C / °F 300 / 572 300 / 572 300 / 572 300 / 572
Temperature
fluctuation
at 70 °C / 158 °F ± K -- 0,1 0,1 0,1
at 150 °C / 302 °F
± K 0,3 0,3 0,3 0,3
at 300 °C / 572 °F
± K -- 0,2 0,3 0,4
Temperature
uniformity
(variation)
at 70 °C / 158 °F
± K 0.8 0.8 0.7 0.8
at 150 °C / 302 °F
± K 2.5 3.0 2.6 2.9
at 300 °C / 572 °F
± K 4.5 6.7 4.6 6.3
Heating up time
to 70 °C / 158 °F
minutes 10 7 20 22
to 150 °C / 302 °F
minutes 25 24 28 27
to 300 °C / 572 °F
minutes 59 60 75 66
Recovery time
after door was
open for 30 sec
at 70 °C / 158 °F
minutes 5 4 3 2
at 150 °C / 302 °F
minutes 6 5 5 6
at 300 °C / 572 °F
minutes 10 9 13 13
Ventilation data
Air change
at 70 °C / 158 °F
x/h 59 59 29 19
at 150 °C / 302 °F
x/h 64 64 32 20
at 300 °C / 572 °F
x/h 53 53 26 18
Electrical data
(model versions FD023-230V, FD053-230V, FD115-230V, FD240-230V)
IP system of protection acc. to EN 60529 IP 20 20 20 20
Nominal
voltage (±10%)
at 50 Hz power frequency V 230 230 230 230
at 60 Hz power frequency V 230 230 230 230
Current type 1N~ 1N~ 1N~ 1N~
Nominal power kW 0.8 1.20 1.60 2.70
Power plug Grounded plug
Chamber fuse
5x20mm / 230V / time-lag M
Amp
10
external
10
external
10
external
16
external
Installation category acc. to IEC 61010-1 II II II II
Pollution degree acc. to IEC 61010-1 2 2 2 2
