BD / BF / ED / FD / FED (E3.1) 02/2022 page 9/116
1.6 Type plate
The type plate is located on the left-hand side of the chamber, bottom right-hand.
Figure 2: Type plate (example FED 115-230V regular chamber)
Figure 3: Type plate (example BD 115-230V optional chamber)
Indications of the type plate (example)
Indication
Information
BINDER
Manufacturer: BINDER GmbH
BD 115
Model designation
Incubator
Chamber name: Incubator
Drying and heating oven
Chamber name: Drying and heating oven
Serial No.
000000000000
Serial No of the chamber
Built
2021
Year of construction
Nominal temperature
100 °C
212 °F
Nominal temperature
IP protection
20
IP type of protection acc. to EN 60529
Temp. safety device
DIN 12880
Temperature safety device acc. to standard DIN 12880
Class
3.1
Class of temperature safety device
Art. No.
9110-0305
Art. no. of the chamber
Project No.
---
Optional: Special application acc. to project no.
1,30 kW
Nominal power
5,7 A
Nominal current
230 V / 50 Hz
Nominal voltage ± 10%
at the indicated power frequency
230 V / 60 Hz
1 N ~
Current type
With option internal socket:
Nominal power: 0,85 kW
With option internal socket: increased total nominal power
Nominal temp.
300 °C
1,30 kW / 5,7 A
572 °F
230 V / 50 Hz
IP protection
20
230 V / 60 Hz
Safety device
DIN 12880
1 N ~
Class
2.0
Art. No.
9010-0305
Project No.
Built
2021
Drying and heating oven
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
FED 115
E3.1
Serial No. 00000000000000
Made in Germany
Nominal temp.
100 °C
0,35 kW / 1,6 A
With option internal socket:
212 °F
230 V / 50 Hz
Nominal power: 0,85 kW
IP protection
20
230 V / 60 Hz
Safety device
DIN 12880
1 N ~
Class
3.1
Art. No.
9110-0325
Project No.
Built
2021
Incubator
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
BD 115
E3.1
Serial No. 00000000000000
Made in Germany
