2.1 Chamber overview
Figure 3: Front view FDL 115
(A) Control panel
(B) Microprocessor program controller RD3
(C) Temperature safety device class 2 according to DIN 12880:2007
(D) Main power switch ON/OFF
(E) Solvent curve
(F) Door handle
(G) Chamber door
