Binder KB 115 (E4) - 17.3.2 Setting Over;Undertemperature Controller

KB (E4 + E6) 02/2017 page 108/148
17.3.2 Setting the Over- and undertemperature safety controller
To display and to change the current safety controller settings in the “safety controller” submenu, go to
Menu > Safety controller
Selection between Limit (absolute) and Offset (relative) safety controller mode
Fixed value
08.03.2015 05:05:06
Submenu “Safety controller”.
Select “Mode”
and press the operating button.
..\ Safety controller
Mode
Overtemperature
Undertemperature
Show settings
Close Home
Fixed value
08.03.2015 05:05:06
Submenu “Safety controller mode”.
The current safety controller mode is displayed:
“Limit (absolute)” or “Offset (relative)”
To change the mode, press the operating button.
The modified safety controller mode is displayed.
..\ Safety controller mode
Limit (absolute)
Close Home
When changing the safety controller mode, the safety controller setpoint which had been active
before in this mode becomes active again.
Entering the safety controller setpoint for overtemperature
Fixed value
08.03.2015 05:05:06
Submenu “Safety controller”
Select “Overtemperature“
and press the operating button.
..\ Safety controller
Mode
Overtemperature
Undertemperature
Show settings
Close Home
