KB (E4 + E6) 02/2017 page 35/148
7.4 Switching on or off the optional object temperature display
For chambers equipped with the digital object temperature display with a flexible Pt 100 temperature sen-
sor (option, chap. 19.4), you can switch on or off the object temperature indication via the controller.
To access the setting menu, go to Menu > Optional equipment > Object temperature display
Fixed value
08.03.2015 05:05:06
Submenu “Object temperature display”.
The current setting is indicated.
To change the setting,
press the operating button.
The modified setting is displayed.
“Object temperature display: Off” = Object tempera-
ture display deactivated
„Object temperature display: On“ = Object tempera-
ture display activated
..\ Object temperature display
Object temperature display: Off
Close Home
Go back to the initial view with “Home”.
7.5 RS 422 address (with optional RS 422 interface)
For chambers equipped with the optional RS 422 interface, the RS 422 address serves to identify the
chamber in a network and to establish communication with the optional BINDER communication software
APT-COM™ 3 DataControlSystem. The factory default setting is “1”.
To enter the RS 422 chamber address, go to Menu > Optional equipment > RS 422 address
Fixed value
08.03.2015 05:05:06
Entry menu “RS 422 address”.
Enter the desired address (1 up to 254)
with the operating button.
Press the “Ok” button to confirm.
..\ RS 422 address
1
1
Pos1 End Ok 0 2 3 4 5 6 7 8 9
Close Ok Home
When entering a value above 254, the message “invalid value” appears. Press the operating button to
confirm with “Ok” and repeat the entry with a correct value.
Go back to the initial view with “Home”.
