KB (E4 + E6) 02/2017 page 34/148
7.2 Switching on or off the optional zero-voltage relay control outputs
For chambers equipped with zero-voltage relay outputs (available via BINDER INDIVIDUAL Customized
Solutions, chap. 19.7), you can switch on or off the output via the controller.
To access the setting menu for the operating modes “Fixed value” and “Control off”, go to
Menu > Optional equipment > Zero-voltage relay control outputs.
The setting for program operation is done through the program editor (chap. 9.3.7).
08.03.2015 05:05:06
Submenu “Zero-voltage relay control outputs”.
The current switching state of the zero-voltage relay
control outputs is indicated. To change it, select the
desired control output
and press the operating button.
The modified switching state is displayed.
“Control output: Off” = zero-voltage relay output
deactivated
“Control output: On” = zero-voltage relay output
activated
..\ Zero-voltage relay control outputs
Close Home
Go back to the initial view with “Home”.
A symbol on the controller display indicates the switching state of the three zero-voltage relay
control outputs, as soon as at least one control output is activated
(example: control outputs 1 + 2 activated)
7.3 Functional test of the optional alarm output
For chambers equipped with the zero-voltage relay alarm output (option, chap. 19.5), you can switch on
the output for test purpose via the controller and then switch it off again.
To access the setting menu, go to Menu > Optional equipment > Functional test – alarm output
08.03.2015 05:05:06
Submenu “Functional test – alarm output”.
The current switching state is indicated.
To change the switching state,
press the operating button.
The modified switching state is displayed.
“Alarm output: Inactive” = alarm output switched off
“Alarm output: Active” = alarm output switched on
(alarm state)
..\ Functional test – alarm output
Close Home
Go back to the initial view with “Home”.
