Parts List – Section 5.2
Parts List – Mechanical Assembly - Carriage 192682
ITEM PART No DESCRIPTION QTY REMARKS
60 192608 LH CARRIAGE END 1
61 192607 CARRIAGE MIDDLE 1
62 192609 RH CARRIAGE END 1
63 192618 CARRIAGE ADAPTOR 1
64 192611 FOLLOWER GUARD WASHER 2

65 192610 CAM FOLLOWER PIN 1
66 192612 FOLLOWER NUT WASHER 1
67 192641 Ø72 CAM FOLLOWER 1

