Parts List – Section 5.2
Parts List – Mechanical Assembly - Carriage 192682
ITEM PART No DESCRIPTION QTY REMARKS
68 192642 LINEAR BEARING 4

69 192615 LINEAR BEARING SPACER 2

70 192652 Ø47 INTERNAL CIRCLIP 4

71 165086 M8 SPRING WASHER 6
72 165553 M8 x 25 CAP HD SCREW 6
73 165552 M8 x 20 CAP HD SCREW 2
74 163152 M16 NYLOC NUT 1
75 192649 1/8 GREASE NIPPLE - SLIP ON 2
76 192661 1/8R - 6MM PUSH IN ELBOW 1
