Manual for VMP300-based instruments
95
Floating mode
Yes
IR compensation
Yes
Analog filtering
Yes
External input/outputs
Yes
Cell connection
2, 3, 4 or 5 terminal leads (+ ground)
Control amplifier
Compliance
± 12 V
Maximum current
± 500 mA continuous
Gain-Bandwidth compensation
9 programmable stability factors
Highest unity gain bandwidth
1.4 MHz
Slew rate (no load)
> 20 V/µs
Rise/Fall time (no load)
< 500 ns
Voltage control
Ranges
Adjustable from ± 10 V down to ± 30 mV (1 mV
resolution)
DC level shift
± 10 V, 300 µV resolution.
For example: For an Erange of [0;20]V, the resolution is
333.33 µV. For [0;19.66]V, the resolution is 300 µV. For
[0;13.1]V, the resolution is 200 µV. For [0; 6.55]V, the
resolution is 100 µV. For [0; 3.27]V, the resolution is 50 µV.
For [0; 1.31]V, the resolution is 20 µV. For [0; 0.65]V, the
resolution is 10 µV. For [0; 0.32]V, the resolution is 5 µV.
For [0; 0.13]V, the resolution is 2 µV. For [0; 0.06]V, the
resolution is 1 µV.
Accuracy
< ± 1 mV ± 0.03% of setting
Lowest resolution
1 µV
Current control
Ranges
± 1 A, ± 100 mA, ± 10 mA, ± 1 mA, ± 100 µA,
± 10 µA, ± 1 µA (7 ranges + Autorange)
Additional ranges
± 100 nA, 10 nA with gain
Accuracy
< ± 0.1 % of range ± 0.03 % of setting
Resolution
0.0033 % of range
Voltage measurement
Ranges
± 10 V, ± 5 V, ± 2.5 V, ± 250 mV, ± 25 mV
DC level shift
± 10 V, 300 µV resolution
Accuracy (DC)
< ± 1 mV, ± 0.03 % of reading
Maximum resolution
< 0.0033 % of range
Bandwidth (-3 dB)
8 MHz
Filtering low-pass 4 poles Sallen-
Key filters
50 kHz, 1 kHz and 5 Hz
Acquisition speed
1,000,000 samples/s
Current measurement
Ranges
± 1 A, ± 100 mA, ± 10 mA, ± 1 mA, ± 100 µA,
± 10 µA, ± 1 µA
Additional ranges
± 100 nA, ± 10 nA
Accuracy (DC)
< ± 0.1 % of range ± 0.03 % of reading
Maximum resolution
0.0033 % of range
Bandwidth (-3 dB)
8 MHz
Filtering low-pass 4 poles Sallen-
Key filters
50 kHz, 1 kHz and 5 Hz
Acquisition speed
1,000,000 samples/s
Electrometer
