37
4.4 Windows Security Alert
When the user tries to find
an instrument in the network
or by USB, the software will
use a broadcast that may be
stopped by windows
firewall. In this case click on
the “Allow access” button:
Fig. 44: “Windows security Alert” window.
4.5 Firmware Upgrading with EC-Lab

software
When the user receives a new unit from the factory, the software and firmware (in the
instrument) are installed and upgraded. The instrument is ready for use. It does not need to be
upgraded. However, when a new EC-Lab

version is released (with new protocols or
improvements) the firmware has to be updated and installed by the user.
4.6 Firmware Downgrading with EC-Lab

software
It is possible to downgrade the firmware of the instrument in an advanced tool available in EC-
Lab

. This procedure should only be done by an advanced user and in very special cases.
Please contact technical support for assistance.
WARNING:
 If the user downgrades the firmware of the instrument, corresponding version of EC-
Lab

must be used. For example, if the firmware of the instrument is the V10.20, the
user must control the instrument with EC-Lab

V10.20.
 Make sure that the older version supports the particular instrument.
Instruments
Lowest compatible version
SP-200
V10.00
SP-240
V10.17
SP-300
V10.00
VSP-300
V10.17
VMP-300
V10.30
The firmware downgrade procedure is as follows:
NOTE:
 the example shows a downgrade from V10.23 to V10.12 but the procedure will be the
same for other versions.
