S3 Cell Sorter Instruction Manual | 3
This chapter describes the hardware of the S3 system. Understanding the system’s hardware is
essential for proper operation.
2.1 System Overview
The S3 system consists of fluidics, optics, electronics, and software. It can be broken down
into several subsystems (Figure 1).
Hardware Description
2
Access to nozzle assembly
Access to internal
fluidics system
Access to filters
Touch locking system
Sort collection area
Loading stage
Fig. 1. Front view of the S3 system.
