E. COMBIPOOL PH/REDOX DESCRIPTION
1. External view
2. Internal view
Digital
display
Setting
buttons
pH probe
connector
Redox pump
pH pump
Automatic control
220V
plug
Redox probe
connector
0,5A fuse
(Time
delay)
On/off
switch
pH probe
connector
220V
supply
connector
Redox
probe
connector
Automatic
control
connector
