H. COMBIPOOL PH/REDOX SETTINGS
1. Start-up
Your Combipool pH/Redox is factory pre-set and delivered ready to use.
Factory settings:
❖ Language: English => refer to paragraph H.4.a.) page 33 to switch to English
❖ Instructions pH: 7.4
❖ Instructions Redox: 720mV
❖ Injection mode: acid => pH minus
❖ Sensor: calibrated
❖ pH-OFA overdose alarm: 40 min
❖ Filtration control (flow = ON)
• Open the casing and remove the bag containing the assembly manual (red)
• Plug in the casing power cable in a 220 V wall outlet
• Set the On / Off switch on the side of the casing to "I"
• The casing screen lights up and after a few seconds displays:
❖ The Redox value in mV
❖ pH value
• Prime the pumps (use the manual injection function)
Refer to the following sections to continue setting up the apparatus. We recommend performing the probe
calibration procedure (see Section I. Probe Calibration, page.16)
2. Manual injections:
a.) pH :
• Press for at least 5s: the pH pump injects the product
• Release : the pump stops immediately
b.) Remanent RX
• Press for at least 5s: the pump injects the product
• Release : the pump stops immediately
3. Set-point adjustment (Quick access)
• From Home screen, press during 1s to access set-points : the pH current set-point displays and the
pH measured value on the side : Sp 7.4pH (set-point value) 14.0pH (measured value)
• Press again: the value flashes and can be modified.
• With or , set the desired new value and then press to validate
• Switch parameter with or , the redox current set-point displays and the redox measured value on
the side : Sp 750mV (set-point value) 0mV (measured value)
• Press again: the value flashes and can be modified.
• With or , set the desired new value and then press to validate
Note : If no button is pressed during 10s, the display returns to the home screen
