A. TECHNICAL CHARACTERISTICS
MP030 EL RANGE 600 W 1 KW 3 KW
REACTOR
Material
Stainless steel 316L
Finish
Pickling and passivated
Maximum service pressure
3 bars
Weight (kg)
(1)
16
Ø and body length (mm)
204 x 276
Overall length (mm)
450
Volume (litres)
14,2
Connection type
Flange
Standard Connection
(2)
DN 80
ELECTRICAL UNIT
Type
Painted steel Painted steel
Dimensions (mm)
600 x 400 x 250 600 x 400 x 250
Weight (kg)
Power supply
Single-phase
240VAC
Power supply wiring
2G1.5mm² 2G2.5mm²
Earth cable
6 mm²
Differential protection
30 mA 30 mA
Thermo magnetic protection
10 A 2P 25 A 2P
Circuit breaker tripping curve
Curve C Curve C
Fuse
-
On / Off switch
Yes
Power on indicator light
Yes
UV lamp indicator light
Yes
Display
Monitor MIII
Protection index
IP 54
UV-C LAMP
Number of lamps
1 1 1
Electrical power
600 W 1 000 W 3 000 W
Unit UV-C power
90 W 150 W 375 W
Total UV-C power
90 W 150 W 375 W
Average lifetime
6 à 9 000 h 6 à 9 000 h 6 à 9 000 h
*operating continuously with one on/off per day.
Turning UV lamps on and off reduces their lifespan. A minimum time delay of 30 minutes must be
observed before turning a lamp back on again.
(1) Caution, with a cleaning system these values change.
(2) Except request specific to the order.
