MP 030 EL NM GB Copyright BIO-UV - 29/01/2009
Marque, Modèles et Brevets déposés - Produits exclusifs
Page 9
D. INSTALLATION OF THE REACTOR
Overall installation view
Reactor in a horizontal position Reactor in a vertical position
Marque, Modèles et Brevets déposés - Produits exclusifs
MP030_SN-GB.doc
Page 9
Copyright BIO-UV - 29/01/2009
LAMPS must be HORIZONTAL
Temperature
Sensor supply
General power
supply
UV lamps power
supplies
Temperature
Sensor supply
General power
UV lamps power
supply
UV lamps power
supply
