Strictly follow the instructions:
Positioning of reactor
Clearance zone (mm) required
to work on the reactor
- The water channel is horizontal.
- The UV lamps are horizontal.
- The purges are at the base of the reactor.
Lamps are in vertical position:
PROHIBITED
Marque, Modèles et Brevets déposés - Produits exclusifs MP030_SN-GB.doc
Page 10
Copyright BIO-UV - 29/01/2009
200
