Biobase BSC-4FA2 - Simple Accessories Replacement

31
doesn’t work
Motor of front
window
Check front window motor
Circuit
Check circuit
Control panel
Change it
Remote control
doesn’t work
Remote control
Check if the Remote control is broken or not,
and if there’s electric in the buttery
Connection cable
Check whether main control panel and
display board is connected well.
Control panel
Change it
No electricity in
equipment
Power supply
Check power supply connects well
Power wire
Check whether power wire has obvious
damage
Fuse
Check if the fuse is good
Power key
Check if power key is open, is broken or not
Transformer
Check whether the transformer works
normally
Control panel
Change it
Display doesn’t
work
Connection winding
displacement
Check whether the winding displacement
connects well.
Display screen
Check whether the display screen is good
NOTES
(1) The above electrical parts must be operated by a qualified electrician in safety conditions
(cutting off power supply). The other parts are not allowed to remove; otherwise the user
should take responsibility by them;
(2) When failures are not occur, and the operator can’t solve, please notify our maintenance
department immediately. For your safety, please do not maintain equipment by yourself;
(3) The maintenance of this equipment is undertaken by trained and recognized technicians;
(4) If you need to order parts, contact the agent or our technical service department, and please
indicate the model and serial number of the cabinet purchased.
3.1.3 Simple accessories replacement
1) Replace fluorescent light
When replacing lights, make sure that the power is off, open the operation panel like shown in
Picture 23, use the control panel support frame (fixed in the inside position of the control panel as
shown), then like Picture 24 shown screwing the tube 90°, take the correspondence type of lamp, put
it to the lamp holder and screw 90 °to the right position.
