Biochrom Anthos Fluido-2 Microplate Washer v2.0 Page 54
Screen
55.
Define Plate Menu
This menu allows to define all parameters for a plate. A defined plate is
required to for a complete wash-procedure.
 Function keys:
<F1> or <F2>
Select another menu.
<+> or <->
Select "<new>" to define a new plate or select an existing plate to edit
it.
<enter>
Confirm the selection of the plate and go to the next screen.
Screen
56.
Plate Name Entry
The name of the plate may be changed.
 Function keys:
<F1> or <F2>
Select “Esc” to return to main menu without saving any changes
Select "Chg" to change the name for the plate.
<enter>
Confirm the existing name and go to the next menu
Screen
57.
Plate Name Entry
 Function keys:
<F1> or <F2>
Select "Esc" to return to the main menu without saving any changes or
"Sel" to select the current letter/number.
<+> or <->
Use these keys to scroll through the available letters (A-Z) and
numbers (0-9)
<enter>
Confirm the name of the plate and go to the next screen.
Def Plate:
<< >> <new>
Name:
Esc Chg 1
Name:
Esc Sel A_
