Biodom C15 | instructions for use, maintenance and installation | February 2019
31
Figure: 9
Always make sure that the pellet boiler and ashes in it are cool.
This is the combustion container for burning pellets (figure 9). We recommend inspecting and cleaning
ashes from the bottom of combustion chamber upon each cleaning. When you place the combustion
container back in its place, make sure that it is set correctly: it must be pushed towards the back wall
all the way. Only then you can be sure that the boiler will function properly.
Figure 10
ATTENTION
Be careful that the sealant rope under the edge of combustion chamber is not damaged. If the
sealant rope is damaged, contact an authorized service centre.
2. An opening for inserting a heating
element for incineration of fuel
.
1. In order to optimize the
operation of the furnace, the
ash must not be collected in
the openings.
