Biodom C15 - Menu Button Usage and Start-up Sequence; Menu Button Usage for Settings; Initial Start-up Sequence

Biodom C15 | instructions for use, maintenance and installation | February 2019
59
-
Button DOWN
Press during operation to decrease set power.
When pressing MENU button beforehand, this button decreases
desired water temperature in the boiler. In menu mode, we select
desired submenu by pressing.
MENU button
Short press in basic display shows set value of water temperature in
the boiler, which can then be modified with buttons + and -.
Press and hold for at least 2 seconds to activate menu mode.
Press and hold for at least 4 seconds to enter advanced menu
settings. Subsequent pressing of the button display menu choices.
Use buttons + and - to select parameters in submenus. Short press
MENU button and set value of parameter starts flashing, which can
then be modified with buttons + and -.
Short press ON/OFF button and hold MENU button to scroll all menu
choices and return to basic display.
When the installer makes the connection to central heating system, to chimney with flue connection
and to electrical network in accordance with instructions for installers, the boiler is ready for start-up.
After checking details from instructions for installers, combustion device Biodom C15 can be
commissioned with ON/OFF button (see figure 14) by the installer, who installed the device.
Upon first start-up, the installer must be careful of correct order of events (displays):
• press and hold ON/OFF button for 3 seconds. Display indicates ON, and immediately after
• "Test fi re" – lasts 10 seconds, then goes to:
• "Heat up" – quick filling of combustion container with pellets, alternately displaying P0 d5 (in
upper display) and changing temperatures; b – temperature of heating water in the boiler, only
number – temperature of smoke gases and r – temperature of return line (in lower display), then
goes to:
• "Fuel igni" – ignition of combustion device Biodom C15 (upon first ignition, ignition phase can
last longer, even up to 10 minutes) lasting approximately 5 minutes, alternately displaying P0 d5
in upper display and temperature in lower display, then goes to:
• "Igni test" – checking ignition, display also changes between igni test and P0 d5, and tempera-
tures in the lower display. When checking is done, it goes to:
• "Burn" – boiler operation, upper display indicates Burn, lower display indicates changing b-tem-
perature of heating water in the boiler, smoke gases and r-temperature of water in the boiler:
