Display of the status of the digital inputs of the
controller:
Menu item Function
F4⇒di⇒diL1
Modbus: 8192
(read only)
Status of controller digital input DI01
Safety chain of ECOLITE condensing unit
OFF = compressor off or safety chain was triggered
On = compressor is running, safety chain is OK
F4⇒di⇒diL2
Modbus: 8193
(read only)
Status of controller digital input DI02
Reserve
F4⇒di⇒diL3
Modbus: 8194
(read only)
Status of controller digital input DI03
Reserve
F4⇒di⇒diL4
Modbus: 8195
(read only)
Status of controller digital input DI04
Reserve
F4⇒di⇒diL5
Modbus: 8196
(read only)
Status of controller digital input DI05
Configurable special function 1st input
OFF = there is no external On command active
On = an external On command is active
F4⇒di⇒diL6
Modbus: 8197
(read only)
Status of controller digital input DI06
Configurable special function 2nd input
OFF = there is no external On command active
On = an external On command is active
