Function of the digital inputs for external signals –
menu di:
Menu item Function
F2+F4⇒PAr⇒di⇒i05
Modbus: 16448
Function of the first controller input for external signals
0 = no function (factory setting)
1 = reserved (do not use)
2 = enable condensing unit
3 = enable compressor
4 = enable condenser fan(s)
5 = set point adjustment active
6 = LowSound mode active
-1 = reserved (do not use)
-2 = enable condensing unit (inverted)
-3 = enable compressor (inverted)
-4 = enable condenser fan(s) (inverted)
-5 = set point adjustment active (inverted)
-6 = LowSound mode active (inverted)
Ex-factory setting: 0 = no function
F2+F4⇒PAr⇒di⇒i06
Modbus: 16449
Function of the second controller input for external signals
0 = no function (factory setting)
1 = reserved (do not use)
2 = enable condensing unit
3 = enable compressor
4 = enable condenser fan(s)
5 = set point adjustment active
6 = LowSound mode active
-1 = reserved (do not use)
-2 = enable condensing unit (inverted)
-3 = enable compressor (inverted)
-4 = enable condenser fan(s) (inverted)
-5 = set point adjustment active (inverted)
-6 = LowSound mode active (inverted)
Ex-factory setting: 0 = no function
The ECOLITE controller is equipped with two configur-
able digital inputs for special functions. 5 special func-
tions are available for each input. If required, the re-
spective special function can be parametrised inverted
(e.g. NC contact available instead of an NO contact)
The same function cannot be used on both inputs at
the same time.
