BIXOLON SRP-350plusIII - Ethernet (Built-In)

SRP-350plusIII/352plusIII
Ver. 2.00
- 14 -
2-2-2 Ethernet (Built-in)
Pint No.
Signal Name
Color
Function
1
TD+
WHITE ORANGE
Transmit +
2
TD-
ORANGE
Transmit -
3
TCT
WHITE GREEN
Receive +
4
NC
BLUE
-
5
NC
WHITE BLUE
-
6
RCT
GREEN
Receive -
7
RD+
WHITE BROWN
-
8
RD-
BROWN
-
Connect or disconnect the communication cable while the printer
power is off. If power is on, your data may be lost.
- IP and MAC information can be obtained from the self-test.
- Refer to the Wireless LAN Connection Manual for more detailed
instructions about how to establish the connection.
The network connection manual is on the BIXOLON website
(www.bixolon.com) We're offering it.
