BIXOLON SRP-350plusIII User Manual

SRP-350plusIII/352plusIII
Ver. 2.00
- 19 -
2-2-7 Powered USB Interface Card
Pin No.
Signal Name
Function
Shield
Shield
Prevent Noise
1
PGND
Main Power Ground
2
VPP24V
Main Power
3
GND
Signal ground
4
D+
Data Line (D+)
5
D-
Data Line (D-)
6
VBUS
Host Power
7
VPP24V
Main Power
8
PGND
Main Power Ground
- Refer to www.powered.org for detailed information related to the
specifications of cable and port.
- Do not apply AC/DC Adapter 24V when using powered USB.
(Powered USB uses its own power.)
- In case of using Powered USB interface, the other USB interface
provided by default is not useful. (In this case, USB communication is
only available through the Powered USB)

BIXOLON SRP-350plusIII Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	50 - 80 µm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
USB port	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
Wi-Fi	No
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, ITF-14, ITF-25, Micro QR Code, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	204 mm
