BIXOLON SRP-350plusIII User Manual

SRP-350plusIII/352plusIII
Ver. 2.00
- 35 -
7. Maintenance
7-1 Paper Jam
• Never force the paper out in the event of a paper jam.
If paper is stuck, turn the printer ON/OFF and open the Printer Cover to remove the
crumpled paper inside the printer. If the cover will not open, please follow the
following instructions.
1) Turn the printer OFF.
2) Pull out the Cutter Cover to separate from the printer.
3) Turn the knob and insert the blade that sticks out using a cross-head screwdriver
as shown below.
4) Push the Cover Open Button and remove the jammed paper.
5) Put the Cutter Cover back in place.
6) Turn the Printer Cover ON and use it.
If the cover does not open, do not forcibly open it.
It may result in poor paper cutting or printer damage.
- Placing your hand above the printer outlet may cause a paper jam.
- In case of a minor jam, it may be possible that the operating
blade returns to the original position by turning the printer OFF and
then back ON.
Cutter Cover
Knob

BIXOLON SRP-350plusIII Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	50 - 80 µm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
USB port	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
Wi-Fi	No
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, ITF-14, ITF-25, Micro QR Code, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	204 mm
