BIXOLON SRP-350plusIII User Manual

SRP-350plusIII/352plusIII
Ver. 2.00
- 37 -
8. Specifications
8-1 Printer Specifications
Printing Method
Thermal transfer printing
Dot Density
SRP-350plusIII: 180 dpi (7dots/mm)
SRP-352plusIII: 203 dpi (8dots/mm)
Printing Width
3-inch
72 mm
2-inch
48 mm
Roll Width
3-inch
79.5±0.5 mm
2-inch
57.5±0.5 mm
No. of Characters per Line
(Default Value)
SRP-350plusIII
: 42 (Font A), 56 (Font B), 56 (Font C)
SRP-352plusIII
: 48 (Font A), 64 (Font B), 64 (Font C)
Printing Speed
SRP-350plusIII: Max. 300 mm/sec
SRP-352plusIII: Max. 270 mm/sec
Receiving Buffer Size
4K bytes
AC/DC Adapter
Input Voltage
100~240 VAC
Frequency
50/60 Hz
Output Voltage
24 VDC
Environment
Condition
Temperature
Operating: 0 ~ 40 ℃
Storage: -20 ~ 60 ℃
Humidity
Operating: 10 ~ 80 % RH
Storage: 10 ~ 90 % RH
Paper excluded
Life Span
Printer Head
150 Km
Auto Cutter
1,800,000 cuts
MCBF
Printer Mechanism
70,000,000 lines
The specifications were determined based on operation at normal
temperature using designated paper on default settings.
They are subject to change depending on temperature or printing
level. Printing speed may become slightly slower depending on
the data transmission speed and the combination of commands.

BIXOLON SRP-350plusIII Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	50 - 80 µm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
USB port	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
Wi-Fi	No
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, ITF-14, ITF-25, Micro QR Code, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	204 mm
