BIXOLON SRP-350plusIII User Manual

SRP-350plusIII/352plusIII
Ver. 2.00
- 27 -
3-4 Using Controller
Explanation
Power LED
The Power LED light is on whenever the printer is on.
Error LED
Error LED is on when there is an error such as no paper roll, open
cover, etc.
Paper LED
Paper LED is on when the paper roll is almost used up or there is
no paper roll inside. Paper LED flickers when the machine is in a
self-diagnosis stand-by or macro execution stand-by state.
Feed Button
Press the Feed button once to output one line of the paper roll.
Press the Feed button for more than 3 seconds to output the
paper roll continuously.

BIXOLON SRP-350plusIII Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	50 - 80 µm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
USB port	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
Wi-Fi	No
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, ITF-14, ITF-25, Micro QR Code, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	204 mm
