BIXOLON SRP-F310 User Manual

Rev. 1.00
- 15 -
SRP-F310/312/313II
1-4 Setting the Dip Switches
1-4-1 Serial Interface
• DIP Switch 1
SW
Function
ON
OFF
Default
1-1
Auto-Cutter Selection
Disable
Enable
OFF
1-2
Handshaking
XON / OFF
DTR / DSR
OFF
1-3
Word length
7 bits
8 bits
OFF
1-4
Parity check
Yes
No
OFF
1-5
Parity selection
EVEN
ODD
OFF
1-6
Baud rate selection
Refer to the Following Table 1
OFF
1-7
ON
1-8
OFF
1-4-2 Parallel / USB / Ethernet / Wireless LAN / Powered USB Interface
• DIP Switch 1
SW
Function
ON
OFF
Default
1-1
Auto-Cutter Selection
Disable
Enable
OFF
1-2
~
1-8
Reserved
-
-
OFF
1-4-3 Bluetooth Interface
• DIP Switch 1
SW
Function
ON
OFF
Default
1-1
Auto-Cutter Selection
Disable
Enable
OFF
1-2
Reserved
-
-
OFF
1-3
SSP Mode
Enabled
Disabled
OFF
1-4
Reserved
-
-
OFF
1-5
Reserved
-
-
OFF
1-6
Reserved
-
-
OFF
1-7
Reserved
-
-
ON
1-8
Reserved
-
-
OFF
Transmission speed
SW1 – 6
SW1 – 7
SW1 – 8
Default
2400 baud
ON
OFF
OFF
9600
4800 baud
ON
OFF
ON
9600 baud
OFF
ON
OFF
19200 baud
OFF
OFF
OFF
38400 baud
OFF
ON
ON
57600 baud
OFF
OFF
ON
115200 baud
ON
ON
ON
Table 1 - Baud Rate Selection
※ Auto Cutter Enable / Disable selection
Dip Switch Set 1
SW1 - 1
ON
Auto Cutter Disable
OFF
Auto Cutter Enable
Application
Ignores Auto Cutter error for continuous printing

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm
