BIXOLON SRP-F310 User Manual

Rev. 1.00
- 23 -
SRP-F310/312/313II
4. Specification
Printing method
Thermal line printing
Dot density
SRP-F310II: 180dpi(7dots/mm)
SRP-F312II: 203dpi(8dots/mm)
SRP-F313II: 203dpi(8dots/mm)
Printing width
SRP-F310II: 72mm
SRP-F312II: 72mm
SRP-F313II: 80mm
Paper width
79.5±0.5mm/82.5±0.5mm
Characters per line (default)
SRP-F310II: 42(Font A), 56(Font B)
SRP-F312II: 48(Font A), 64(Font B)
SRP-F313II :53(Font A), 71(Font B)
Printing speed
SRP-F310II: 82.74 lines/sec, Max. 350mm/sec
SRP-F312II: 93.33 lines/sec, Max. 350mm/sec
SRP-F313II: 93.33 lines/sec, Max. 350mm/sec
Receive Buffer Size
4K Bytes
※ NOTE: Printing speed may be slower, depending on the data transmission
speed andthe combination of control commands.
Supply voltage
SMPS Input voltage
100~240VAC
Frequency
50/60Hz
SMPS Output voltage
24VDC
Environmental
Conditions
Temperature
0~40 ℃ (Operating)
-20~60 ℃ (Storage)
Humidity
10~80 % RH (Operating)
10~90 % RH (Storage)
; Except for paper
LIFE *
Printer Head *)
250 Km
Auto Cutter
3,000,000 Cut
MCBF *
Printer Mechanism *)
70,000,000 lines
*) The specifications were determined based on operation at normal temperature
using designated paper on default settings. They are subject to change
depending on temperature or printing level.
*) The specifications were tested according to standard reliability.
If you want to test the product to determine its life cycle, please contact us for
more details and comply with the standard reliability for testing.
** The switch is the disconnecting device. Turn off switch from any hazard.

BIXOLON SRP-F310 Specifications

General

Color	No
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Maximum printing width	72 mm
Network ready	Yes
Ethernet LAN	-
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power requirements	AC 100-240V / DC 24V, 2.5A
Compatible operating systems	Windows, Mac, Linux Kernel 2.4.18+
Number of fonts	3
Built-in barcodes	CODABAR (NW-7), EAN13, EAN8, ITF-14, UPC-A, UPC-E
Operating temperature (T-T)	0 - 45 °C
Maximum roll diameter	105 mm
Supported paper width	80 - 83 mm

Weight and Dimensions

Depth	203 mm
Width	154 mm
Height	148 mm
Weight	2000 g
