Bizerba BRS 38 - Technical Data and Dimensions

1.4 Dimensional drawing/technical data
6.009.98.5.10.02
GENERAL INSTALLATION
OPERATION
ELEMENTS
OPERATION/
SLICING
CLEANING ACCESSORIES
OPERATION
CONDITIONS
BLADE
REPLACE-
MENT
Weight = approximately 63 kg
Blade diameter = 250 mm
Number of blade revolutions = 700 U/min.
The most important technical data
Max. height of product --round = 300 mm
--oval = 300 x 380 mm
Max. height of product --round = 150 mm
--rectangular = 125 mm
Slice thickness control, = 5 to 30 mm
infinitely variable
Type of current, voltage, = see specification plate
Power consumption
LENGTH
Outside dimensions
max. space required
L B H
964 mm 658 mm 520 mm
Supporting area
L1 B1
440 mm 584.5 mm
WIDTH
7
