Bizerba BRS 38 - Product Clamp and Slice Holder

3.3 Product clamp
The product clamp is only used when slices are
cut.
It clamps the product to be cut.
After closing the protective cover and pressing
the key” Individual slices” it moves to the left,
according to the set slice thickness.
OPERATION ELEMENTS
6.009.98.5.10.02
3.4 Slice holder
The slice holder as well is only used when sli-
ces are cut.
It is placed on the left side of the product to be
cut and prevents the slices from moving or fal-
ling out during the cutting process.
The slice holder is on its shaft and is movable
over half of the machine width.
16
