1.4 Rear Panel Overview
Rear Panel Description
Modulation Input BNC
External Trigger/Gate/FSK/Burst BNC Connector
USB interface
AC input receptacle
Chassis ground
Sync Output BNC
Trigger Input BNC
1
2
3
4
6
7
5
1
2
3
4
5
6
7
