22
Waveforms
Keys
Sine
Sine
Square
Square
Ramp
Ramp
Pulse
Pulse
Noise
Noise
Arbitrary
Arb
After the waveform selection, menu options relevant for that waveform shape will be shown
on the right side of the display. Below illustrates the screenshots shown when each of the
waveform types is selected.
Sine Waveform
Square Waveform
Ramp Waveform
Pulse Waveform
Noise Waveform
Arbitrary Waveform
