75
AC Coupling
1 Hz – 100 MHz, 50 mVrms - 5 Vpp
100 MHz – 200 MHz, 100 mVrms – 5 Vpp
Pulse width/Duty cycle
Voltage Range
50 mVrms – 5 Vpp
Input Impedance
1 MΩ
Coupling
AC, DC
Trigger Level Range
-3 V to +1.8 V
General
Display Resolution
3.5” TFT-LCD Display, 320 x 240
Remote Control
Interface
USBTMC (standard), GPIB (optional)
Storage Memory
10 Instrument settings, 10 Arbitrary waveforms
Dimensions (WxHxD)
213mm x 89 mm x 281 mm (8.4” x 3.5” x 11.1”)
Weight
2.6 kg (5.7 lbs)
Power
100 – 240 VAC ± 10%, 50 / 60 Hz ± 5%
100 – 120 VAC ± 10%, 45 – 440 Hz
Power Consumption
50 W max.
Temperature
Operation: 0 °C – 40 °C
Storage: -20 °C – 60 °C
Humidity
< 35 °C, ≤ 90 % RH
35 °C – 40 °C, ≤ 60 % RH
Altitude
Operation: Below 3,000 m
Storage: Below 15,000 m
