Installation
Unpacking the instrument
This instrument was carefully inspected before shipment. Upon receipt,
inspect the instrument for damage that might have occurred in transit. If any
sign of damage is found, notify your B+K Precision distributor.
Check the list of supplied items
Verify that you have received the following items with your power supply. If
anything is missing, contact your authorized B+K Precision distributor.
- Power cord
- Instruction manual
Power Requirements
The 9110 can operate on 110V AC or 220V AC. Before connecting the power
cord to an AC outlet, make sure the voltage selector in the rear is set to the
correct line voltage.
If necessary, replace fuses according to this table.
The instrument power fuse is located in a fuse compartment below the AC
input receptacle. To access the fuse, first disconnect the power cord and then
remove the fuse cartridge.
Power-on procedure
Turn on the instrument by pressing the main power switch on the front panel
of the unit. The instrument will automatically revert to the last setting before
the power was turned off.
T0 2.5A, 250V198V to 242V220V AC
T0 3.15A, 250V99V to 121V110V AC
FuseRangeLine voltage
The 9 pin D-sub connector in the rear is for factory use only!
This instrument does not offer a remote control interface.
Note
