68
Save Group
81
82
83
84
85
86
87
88
89
90
PROGRAM 10
Sequence
1
2
3
4
5
6
7
8
9
10
Save Group
91
92
93
94
95
96
97
98
99
100
The following is a step-by-step tutorial on how to set up a test file.
Panel Operations VFD Display
1. Power on the electronic load. Self-test
2.
Select the channel you want to edit and then edit every group’s
step. For this example, we will select channel 3 and channel 5
below. Press  keys to switch channel to 3.
CH03 CC OFF
Vdc=0.0000V
Adc=0.0000A
Wdc=0.00W
3.
Press Setup key to enter the channel setup menu, press Enter
key to enter the <Mode> selection menu and press  key to
select the operating mode. Every step’s mode can be edited.
Press Enter key to confirm.
MODE= CC
RANGE= HIGH
Iset= 1.00A
4. Press  key to select <ISet>. Press Enter to enter the menu and
set the working current. For example, to set 1A, press ① and
then Enter to confirm.
Const Current
Set= 1.000A
5. Press  key to move the cursor to Vmax=82.000V and press
Enter to set the upper limit of testing voltage. In this example,
the first step is 5.8V. Press ⑤  ⑧ and then Enter to confirm.
Voltage Upper
Limit= 5.800V
6. Press  key to move the cursor to Vmin=0.000V and press Enter
to set the lower limit of testing voltage. In this example, the first
step is 0.15V. Press  ① ⑤ and then Enter to confirm.
Voltage Lower
Limit= 0.150V
7. After editing the first step of channel 3, press Esc key to exit the
menu.
8. Press  keys to select channel 5. To edit the first step of
channel 5, repeat steps 3 through 6 with desired parameters.
CH05 CC OFF
Vdc=0.0000V
Adc=0.0000A
Wdc=0.00W
