69
9.
After editing the first step of channel 5, press Esc key to exit the
menu.
10. Save the edited first step of channel 3 and channel 5. Press Save
and ① to save step 1. Press Enter to confirm.
Save Group
1
11. In the same manner, you can edit the rest of the steps for
channel 3 and channel 5 by repeating steps 2 through 10 above.
These saved groups correspond to sequences that will be
selected in your program below.
12. Press Shift + ⑨ key to enter the Program menu. Press key to
select <Edit Program> and press Enter.
Run Program
Recall Prog
Edit Program
Exit
13. The MDL Series with mainframe extension can support a
maximum of 16 channels. 0 represents the MDL001 mainframe
and 1 represents the MDL002 mainframe extension. □7□5□3□1
indicates channels 1, 3, 5, and 7 have been equipped with
electronic load modules.
Active Channel
0 : □ 7 □ 5 □ 3 □ 1
1 : □□□□□□□□
14.
Select the channels to be tested. For instance, if you want to
select channels 3 and 5, press number keys 3 and 5. ‘Y’ denotes
the channel is selected. If you want to cancel a channel, press
the number key again to cancel. Then press Enter to confirm
your selection.
Active Channel
0 : □ 7 □ 5 □ 3 □ 1
1 : □□□□□□□□
15. Select the steps needed to test. For example, if you want to
test 4 steps, press 1 2 3 4 (0 stands for the tenth step). If you
want to cancel a step, press the number key again to cancel.
Press Enter to confirm your selection.
Active SEQ.
0 9 8 7 6 5 Y Y Y Y
16. If you want to suspend a step, press the number key of the
step. For example, to suspend step 2, press 2. Press the
number key again to cancel. Then press Enter to confirm your
selection.
Pause Sequence
□□□□□□ 4 3 Y 1
