Installation and Programming GPH-CMD VHF Radio
Page 2-10 BK RADIO
OPTIONS 6 – 8: RESERVED FOR FUTURE OPTIONS
Once each option is set as desired, you can store the changes,
discard the changes, or disable all displayed options.
Press the [CLR] key to disable all displayed options (steady).
Press the [ENT] key to store new displayed options settings into
memory and advance to the next field.
Press the [FCN] key to advance to the next field without saving
changes.
2.2.1.4.4 AUTOMATIC NUMERIC IDENTIFICATION (ANI)
After the Global Options are set, the display will indicate the ‘ANI
ID’ number (as many as seven digits may be used). The ID
number can be used for either radio management or transmitted
as a DTMF tone burst for ANI purposes. The ANI can be
enabled or disabled. See “ANI/DTMF Mode” in section 2.2.1.4.3
above.
If no change is needed for the ID number, press the [FCN] key to
advance to the next field.
A new number can be entered by pressing number keys. The
digits will appear at the right of display and move to the left.
Press the [ENT] key to store the new ID number and advance to
the next section.
The existing ID number can be incremented one digit by
pressing the [PRI] key.
Press the [ENT] key to store the new ID number and advance to
the next field.
2.2.1.4.5 TRANSMITTER TIME-OUT TIMER
After the ID number is set, the ‘Transmitter Time-Out Timer’
field is displayed. 0 SEC means the Time-Out Timer is disabled.
Press the [PRI] key to increase the Time-Out Timer duration by
15 seconds, with a maximum of 225 seconds (3 minutes, 45
seconds). Press the [PRI] key again to change the duration from
225 seconds to zero.
Press the [CLR] key to set the Time-Out Timer duration to zero.
Press the [ENT] key to store the changed setting and advance to
the next field.
Press the [FCN] key to advance to the next field if no change is
needed.
PROG ID
ANI 1234567
Ani id num
PROG TX
225 sec
tx timeout
