GPH-CMD VHF Radio Illustrated Parts List
BK RADIO System Board (309-610 Rev. A) Page 6-21
Item Reference Number Part Number Description
C107 1570-02106-778 Cap,CP,10uF,X5R,10%,1206
C108 1570-03150-163 Cap,CP,15pF,NPO,5%,50V,0402
C109 1570-03150-163 Cap,CP,15pF,NPO,5%,50V,0402
C110 1570-03103-261 Cap,Cp,.01uF,5%,X7R,16V,0402
C111 1570-00104-272 Cap,Cp,.1uF,10%,X7R,25V,0603
C112 1570-00102-163 Cap,CP,1.0nF,5%,COG,50V,0603,
C113 1570-00102-163 Cap,CP,1.0nF,5%,COG,50V,0603,
C114 1570-03101-263 Cp,Cap,100PF,X7R,5%,0402
C115 1570-03470-163 Cap,Cp,47pF,NPO,5%,50V,0402
C116 1570-03470-163 Cap,Cp,47pF,NPO,5%,50V,0402
C117 1570-03470-163 Cap,Cp,47pF,NPO,5%,50V,0402
CR1 4824-30599-702 DI,SCHOTTKY,SOD-123
CR2 4824-30599-702 DI,SCHOTTKY,SOD-123
CR3 4824-50483-300 Di,Pin,SOT-23,
CR4 4824-30575-401 Di,Var,SOD.323
CR5 4824-20021-100 Di,Var,SOT-23,
CR6 4824-20008-500 Di,Sil,Switching-Dual,SOT-23,
CR7 4810-20009-303 Di,LED,Red,
FB1 2503-20022-300 Ferrite,Bead,Surfc,Mt
FB2 2503-20022-300 Ferrite,Bead,Surfc,Mt
FB3 2503-02102-410 Bead
FB4 2503-02102-410 Bead
FB5 2503-02102-410 Bead
FB6 2503-02102-410 Bead
FB7 2503-02102-410 Bead
FB8 2503-02102-410 Bead
FB9 2503-02121-505 Bead,Fer.
FB10 2503-02102-410 Bead,Ferrite,
FB11 2503-02121-505 Bead,Fer
FB12 2503-02121-505 Bead,Fer.
FB13 2503-02102-410 Bead,Ferrite
FB14 2503-02102-410 Bead,Ferrite
FB15 2503-02121-505 Bead,Fer.
FB16 2503-02121-505 Bead,Fer.
FB17 2503-02102-410 Bead,Ferrite
FB18 2503-02102-410 Bead,Ferrite
J7 2105-20017-606 Conn,Box_Strip,
J8 2105-20017-606 Conn,Box_Strip,
L1 1808-20013-617 Ind,Fxd_Coil,220NH,SMD
L2 1808-20013-614 Ind,Fxd_Coil,120NH,SMD
L3 1808-20013-618 Ind,Fxd_Coil,270NH,SMD
L4 1808-20013-619 Ind,Fxd_Coil,330NH,SMD
L5 1808-20013-628 Ind,Fxd_Coil,1000NH,SMD
L6 1808-20013-628 Ind,Fxd_Coil,1000NH,SMD
L7 1812-15003-020 Ind,Fxd_Coil,15nH,5%,0805
L8 1812-10014-251 IND,Fxd,Pwr,10 uH,10%
P1 2105-20035-821 Conn,Hdr,3_Pin,
P2 2105-20035-705 Conn.Square,5_Pin,.025Sq
