ENGLISH
30
• Connect the water supply to the power cleaner.
For instructions on connecting the water supply
to the power cleaner, please refer to Attaching
Garden or Suction Hose under Assembly
andAdjustments.
• Connect the pressure spray wand, soap bottle, or
other attachment. For instructions on connecting
the pressure spray wand, please refer to To
Attach the Spray Wand under Assembly
andAdjustments.
Preparing the Power Cleaner (Fig. K)
IMPORTANT: D isengage the trigger lock-off
4
, squeeze the
trigger
7
and hold the trigger for 30 seconds to purge the
system of air. If air is still found in the water stream, continue to
run water through the sprayhandle.
1. Disengage the trigger lock-off
4
.
2. Squeeze the trigger
7
.
Cleaning a Surface (Fig. K)

WARNING: Risk of injury from spray. Always engage
the trigger lock when gun is not in use. Failure to do so
could cause accidentalspraying.
1. To start the pressure cleaner, disengage the trigger lock-
off
4
and squeeze the trigger
7
.
NOTE: The best angle for spraying water against
acleaning surface is 45°. Spraying head on tends to cause
dirt particles to embed in the surface. When working on
vertical surfaces, it is best to apply detergent starting at
the bottom and working upwards which will prevent the
detergent from sliding down and causingstreaks.
2. Select the spray fan for your application.
• Start by opening the nozzle clockwise to a
• wide fan pattern. This will distribute the impact of
the water over alarger area, resulting in excellent
cleaning action with areduced risk of surface
damage, large surface areas can be cleaned more
quickly using awide fan pattern.
• By turning the nozzle tip counterclockwise
anarrow stream will be achieved. This setting
will have ahigh impact force on the cleaning
surface and results in maximum deep cleaning in
aconcentrated area. However, this narrow high
impact spray must be used cautiously, as it may
damage some surfaces.
• To stop the pressure cleaner, release thetrigger.
NOTE: Excessive pump pressure may be the result of
aclogged nozzle. Always turn off the pressure cleaner and
remove the battery before attempting to unclog anozzle.

WARNING: Never draw from water that contains
chemicals. Only draw from fresh water sources.
Shutdown (Fig. A)
1. To stop the pressure cleaner, release thetriggerand
remove thebattery .
2. Turn off water at thefaucet.
3. Discharge residual pressure by squeezing the trigger
7
until no more water comes out of the spray wand
9
.
4. Disconnect the garden hose from the transparent filter
3
and drainhose.
5. Remove garden hose from pressure cleaner by pulling
back the collar on the quick connect hose adapter and
removing it from the transparent filter.
MAINTENANCE
Your BLACK+DECKER tool has been designed to operate
over along period of time with aminimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning. Your charger does not require any
maintenance apart from regular cleaning.

WARNING! To reduce the risk of serious personal
injury, turn off the tool and disconnect it from
the power source before making adjustments or
removing / installing devices or accessories. An
accidental start could cause injuries.

IMPORTANT! To ensure product Safety and
Reliability, repairs, maintenance and adjustment
(other than those listed in this manual) should be
performed by authorized service centers or other
qualified organizations, always using identical
replacement parts. Unit contains no user service able
parts inside.
CLEANING

WARNING! Blow dirt and dust from all ventilation
ducts with dry air, at least once aweek. To reduce
the risk of injury, always use safety goggles when
performing this task.

WARNING! Never use solvents or other abrasive
chemicals to clean non-metallic parts of the tool. These
chemicals can weaken the plastic materials used in these
parts. Use acloth dampened only with water and neutral
soap. Never allow liquid to penetrate inside the tool or
immerse any of the parts in aliquid.
Nozzle
If the nozzle becomes clogged with foreign materials,
such as dirt, excessive pressure may develop. If the nozzle
becomes partially clogged or restricted, the pump pressure
will pulsate. Clean the nozzle immediately.
1. Shut off the pressure cleaner
2
and turn off the
watersupply.
2. Pull trigger
7
on main handle
1
to relieve any
waterpressure.
3. Remove from the pressure cleaner unit by pushing in and
turning the attachment counterclockwise and then pull
from the pressure cleaner
2
.
4. Unclog any debris from thenozzle.
5. Run water from afaucet or garden hose through
thenozzle.
Suction Hose
1. To clean the suction hose 
12
, shut off the
pressurecleaner.
2. Pull trigger switch to relieve any waterpressure.
