CHAPTER 4: ANALOG PORT OPERATION
45
-or-
Double-click on a server’s name or port.
-or-
Press and hold the
Alt key and then click the number of the server you wish
to scan. You can select up to 16 servers.
4. In the Scan Time box, type the number of seconds (from 3-99) of desired time
before the scan moves to the next server in the sequence.
5. Click OK.
To remove a server from the scan list:
1. In the Scan dialog box, deselect the checkbox next to the server to be removed.
-or-
Double-click on a server’s name or port.
-or-
Click the Clear button to remove all servers from the scan list.
2. Click OK.
To start the scan mode:
1. If the OSD is not open, press
Print Screen. The Main dialog box will appear.
2. Click Commands. The Commands dialog box appears.
Figure 4-23. Commands Dialog Box
3. Select Scan Enable in the Commands dialog box.
4. Click X to close the Commands dialog box.
NOTE:
Scanning will begin as soon as the OK button is clicked.
