Mini Converter UpDownCross
39
Switch 1 - Processing Off - Processing On
When switch 1 is set to OFF all conversions are bypassed and the Mini Converter can be used to distribute
your video to six SDI devices.
Mini Switch Settings Example: Set the converter to up convert 4:3 625i50 video to 1080i50 with the
4:3 Pillarbox aspect ratio by setting switches 8 and 7 to the OFF position and switches 3, 2 and 1 to the
ON position.
Mini Converter UpDownCross Conversion Table
Input Video NTSC (Switches
1 and 2 ON)
PAL (Switch 1
ON)
720p (Switches 1
and 3 ON)
1080 (Switches 1,
2 and 3 ON)
525i59.94 525i59.94 625i50 720p59.94 1080i59.94
625i50 525i59.94 625i50 720p50 1080i50
720p50 525i59.94 625i50 720p50 1080i50
720p59.94 525i59.94 625i50 720p59.94 1080i59.94
720p60 525i59.94 625i50 720p60 1080i60
1080PsF23.98 525i59.94 625i50 720p59.94 1080PsF23.98
1080p23.98 525i59.94 625i50 720p59.94 1080p23.98
1080PsF24 525i59.94 625i50 720p50 1080PsF24
1080p24 525i59.94 625i50 720p50 1080p24
1080p25 525i59.94 625i50 720p50 1080p25
1080p29.97 525i59.94 625i50 720p59.94 1080p29.97
1080p30 525i59.94 625i50 720p60 1080p30
1080i50 525i59.94 625i50 720p50 1080i50
1080i59.94 525i59.94 625i50 720p59.94 1080i59.94
1080i60 525i59.94 625i50 720p60 1080i60
1080p50 525i59.94 625i50 720p50 1080p50
1080p59.94 525i59.94 625i50 720p59.94 1080p59.94
1080p60 525i59.94 625i50 720p60 1080p60
2048x1556PsF23.98 525i59.94 625i50 2048x1556PsF23.98 2048x1556PsF23.98
2048x1556PsF24 525i59.94 625i50 2048x1556PsF24 2048x1556PsF24
2048x1556PsF25 525i59.94 625i50 2048x1556PsF25 2048x1556PsF25
