Connecting to a Network
21
Ethernet Network Switch Connection Diagram
If you want to connect several units to your studio's existing network, you only need to connect one unit to
the network switch. The rest can be daisy-chained to each other so you don't have to run multiple cables
back to a network switch. Power must be supplied to all units.
Network Switch
Ethernet
Client
Computers
