Developer Information
30
DATA
STREAM
1
G2041 G2042 G2043 G2045 G2046 G2047
EAV(3FFh)
EAV(000h) EAV(000h)
EAV(XYZh)
LN0 LN1
CRC0 CRC1
ANC/AUDIO
DATA
SAV(3FFh)
SAV(000h) SAV(000h)
SAV(XYZh)
G1 G2 G3 G5
DATA
STREAM
2
B2041 B2042
G2044
B2045 B2046
G2048
EAV(3FFh)
EAV(000h) EAV(000h)
EAV(XYZh)
LN0 LN1
CRC0 CRC1
ANC/AUDIO
DATA
SAV(3FFh)
SAV(000h) SAV(000h)
SAV(XYZh)
B1 B2
G4
B5
DATA
STREAM
3
R2041
B2043 B2044
R2045
B2047 B2048
EAV(3FFh)
EAV(000h) EAV(000h)
EAV(XYZh)
LN0 LN1
CRC0 CRC1
040
…
040
SAV(3FFh)
SAV(000h) SAV(000h)
SAV(XYZh)
R1
B3 B4
R5
DATA
STREAM
4
R2042 R2043 R2044 R2046 R2047 R2048
EAV(3FFh)
EAV(000h) EAV(000h)
EAV(XYZh)
LN0 LN1
CRC0 CRC1
200
…
200
SAV(3FFh)
SAV(000h) SAV(000h)
SAV(XYZh)
R2 R3 R4 R6
WORD#
23.98/24
PsF
1870 1871 1872 1873 1874 1875
1 2 3 4 5 6 7 8 9
…
335 336 337 338 339 340 341 342 343
WORD#
25 PsF
1795 1796 1797 1798 1799 1800
1 2 3 4 5 6 7 8 9
…
260 261 262 263 264 265 266 267 268
Blackmagic 2K Format – Data Stream Format
This diagram shows the data stream formats around the optional ancillary data section of the
horizontal line. Note that each active pixel takes up three samples.
