LB Hex™ Unplugged Manual Rev. A © 2018 Blizzard Lighting, LLC
DMX Values In-Depth (13-Channel Mode)
CH Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Red Intensity (0% <-> 100%)
3 000 <--> 255 Green Intensity (0% <-> 100%)
4 000 <--> 255 Blue Intensity (0% <-> 100%)
5 000 <--> 255 Amber Intensity (0% <-> 100%)
6 000 <--> 255 UV Intensity (0% <-> 100%)
7 000 <--> 255 White Intensity (0% <-> 100%)
8
000 <--> 005
006 <--> 055
056 <--> 105
106 <--> 155
156 <--> 205
206 <--> 255
Strobe
No Function
Random Strobe
Pulse Strobe
Average Strobe
Thunder Strobe
Standard Strobe
9
000 <--> 001
002 <--> 043
044 <--> 085
086 <--> 127
128 <--> 169
170 <--> 211
212 <--> 254
255
Color Macros
No Function
Red Fade In
Red Fade Out <--> Green Fade In
Green Fade Out <--> Blue Fade In
Red Fade In <--> Blue
Red <--> Green Fade In <--> Blue
White Fade In
White (RGBW)
10
000 <--> 005
006 <--> 015
016 <--> 025
026 <--> 035
036 <--> 045
046 <--> 055
056 <--> 065
066 <--> 075
076 <--> 085
086 <--> 095
096 <--> 105
106 <--> 115
116 <--> 125
Color Presets
No Function
Red
Green
Blue
Lime Green
Yellow Green
Yellow
Congo Red
Light Orange
Wine Red
Pink
Pink Purple
Light Purple
126 <--> 135
136 <--> 145
146 <--> 155
156 <--> 165
166 <--> 175
176 <--> 185
186 <--> 195
196 <--> 205
206 <--> 215
216 <--> 225
226 <--> 235
236 <--> 245
246 <--> 255
Pink Blue
Light Blue
Sky Blue
Light Cyan
Cyan Green
Water Green
Light Green
Cold White
Lt. Cold White
Pure White
Purple White
Cream White
Warm White
11
000 <--> 010
011 <--> 040
041 <--> 070
071 <--> 100
101 <--> 130
131 <--> 160
161 <--> 190
191 <--> 220
221 <--> 255
Auto/Sound Active
No Function
7-color Fade
R/G/B Fade
R/G/B Fade 2 (low temp)
7-color Jump
R/G/B Jump
Yellow/Cyan/Magenta Jump
Sound Active Strobe
Sound Active Jump
