DMX Values In-Depth (8-Channel Mode)
CH Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Red Intensity (0% <-> 100%)
3 000 <--> 255 Green Intensity (0% <-> 100%)
4 000 <--> 255 Blue Intensity (0% <-> 100%)
5 000 <--> 255 Amber Intensity (0% <-> 100%)
6 000 <--> 255 UV Intensity (0% <-> 100%)
7 000 <--> 255 White Intensity (0% <-> 100%)
8
000 <--> 005
006 <--> 055
056 <--> 105
106 <--> 155
156 <--> 205
206 <--> 255
Strobe
No Function
Random Strobe
Pulse Strobe
Average Strobe
Thunder Strobe
Standard Strobe
DMX Values In-Depth (13-Channel Mode), continued
CH Value What It Does
12 000 <--> 255 Auto Speed (slow <--> fast)
13
000 <--> 020
021 <--> 040
041 <--> 060
061 <--> 080
081 <--> 100
101 <--> 255
Dimming Curves
Standard Curve
Dimming Curve 1
Dimming Curve 2
Dimming Curve 3
Dimming Curve 4
No Function
Troubleshooting
Symptom Solution
Beam is Dim Check optical system and clean excess dust/grime.
No Light Output Isthextureisoperatingundercorrectmode?
Chase Speed Fast/Slow Check to ensure proper setup of speed adjustment.
No Power Check fuse, AC cord and circuit for malfunction.
Blown Fuse Check AC cord and circuit for damage, verify that
moving parts are not restricted and that unit’s venti-
lation is not obstructed.
Fixture Not Respond-
ing/Responding Errati-
cally
Make sure all connectors are seated securely.
Use only DMX cables or check cables for defects.
Install a Terminator.
Resetxture(s).
If your problem persists or isn’t listed, please open a support ticket
online at: www.blizzardlighting.com/support.
