Page 7
LB Hex™ Unplugged Manual Rev. A © 2018 Blizzard Lighting, LLC
Figure 1: The LB Hex™ Unplugged Pin-Up Picture
Figure 2: The Rear Connections
6* 6-watt
RGBAW+UV LEDs
Heavy-Duty
Cast
Aluminum
Enclosure
Dual
Mounting
Yokes
Locking
Adjustment
Knobs
DMX In
Power In Power Out
DMX Out
Control
Menu
Power
Switch
