Bluetti ACB300 - Page 40

37
Rated Output Frequency 50/60Hz
Rated Continuous Power 3000W
Rated Output Current 30A 25A 13A
Power of Over-load
3100W ＜ load ＜ 3750W, 2min;
3750W ＜ load ＜ 4500W, 5s;
4500W ＜ load ＜ 6000W, 500ms
Eciency >88%
THD <5%
DC Output
Cigarette Lighter Port *1 24VDC,10A
USB-A *2 5VDC,3A,15W total
USB-A(fast charging) *2 3.6-12VDC,3A;18W*2 total
USB-C (Type-C) *1 5-15VDC,3A;20VDC,5A,100W
Wireless Charging Pad *2 5/7.5/10/15W*2
RV Port *1 12VDC,30A 418W>load, 2S
AC Input
Input Voltage 85-110VAC/JP 102-132VAC/US
207-253VAC
EU/UK/AU
Input Frequency 47Hz-63Hz
Max. Input Current 30A
Congurable Input Current Preset at 15A, can be changed on screen
AC Charging Voltage Range 90-264VAC
AC Charging Frequency Range 47Hz-63Hz
Power of Charging 3000W Max
PV Input
Max. Input Voltage 150VDC
MPPT Voltage Range 12-150VDC
Max. Power of Input 1200W*2
Rated Input Current 12A*2
