Max. Torque: 6Nm
Max. Torque: 1.2Nm
1. Inverter BAT- terminal (Black)
2. Black battery power cable (BAT-)
3. M8*12 screws
4. Black protection cover (BAT-)
5. M4*12 screws
Max. Torque: 6Nm
Max. Torque: 1.2Nm
1. Inverter BAT+ terminal (Red)
2. Red battery power cable (BAT+)
3. M8*12 screws
4. Red protection cover (BAT+)
5. M4*12 screws
1
2
3
4
5
Figure 6-9-3
Figure 6-9-4
