JUST POWER ON 63
Follow the diagram below for the correct CT direction from the grid-tie inverter to
the grid.
The arrow points to the grid.
GRID-L
Figure 6-14
On_Grid Breaker
Transfer Switch
Main Breaker
QF
QF
B500
+
-
Backup Loads
PV Input
Backup
Grid
Bat Input
RCDRCD
RCD
CT
CT-1
Non-essential Loads
Solar
+
-
EP760
L
N
PE
N
L
PE
5
1
84
62
L
N
PE
L
N
PE
L
N
PE
Figure 6-15 DC Coupling
